Oil-injected screw compressors VMX

Rotary screw compressors

Ask for a quote

Presentation

Aerzen VMX-screw compressors with oil injection are designed for intake flow volumes from 70 up to 3180 m³/h at driving speeds of 50 resp. 60 Hz and an overpressure – single-stage – up to 13 bar (higher pressures or admission pressure operation upon request).

The drive is effected via V-belt resp. toothed belt or directly via a flexible coupling from the driving motor to the male rotor of the air end. Drive by electric motors or internal combustion engines. All stages are suitable for frequency converter-operation (standard).

VMX screw compressors are supplied as components to manufacturers of mobile and of stationary air compressor plants who produce themselves the accessories or plant components- as oil coolers, oil separators, base frames, etc. – and carry out the final completion of the whole plant unit.

The interactive 3D/360°-view of the VMX and VMW stages offers a rotation- and zoom function. You may also choose between the interior view and the exterior view.
