MSD Diameter and Ovality Measuring Heads

MSD* Diameter and Ovality Measuring Heads A Novel Kind of Diameter Measurement Based on "Multi-Source Device" Technology With the MSD diameter gauges, ZUMBACH® introduces a new series of measuring heads for on-line diameter and ovality measurement and control. This new line complements the high-precision laser diameter measuring heads of the ODAC® series. The MSD models achieve their ideal efficiency in terms of price and performance specifically for applications in the cable and plastics industry. The experience of 55 years with on-line and off-line measurement and control technology has led to a product characterised by the most current and sophisticated technology and functionality as well as by the well-known ZUMBACH® accuracy and reliability. * = Multi-Source-Device Application The MSD models are suitable everywhere and can be used in all cable manufacturing lines for measuring all kinds of wires and cables. They are indispensable tools in tube and hose extrusion lines for measuring pressure, waste water, heating tubes, etc. as well as all kinds of hoses. MSD devices can also contribute to quality monitoring for cold applications in the steel and metal industry. Thanks to the new and unique ZUMBACH® concept of up to 8 light sources (models MSD 100 & MSD 200), multiple shadows on each axis can be evaluated (1 shadow = 1 axis). This allows a multi-axis measurement of smaller products (pat. pend.). Model MSD 50 MSD 100 MSD 200 Number of measuring axis 2 2 (4*) 2 (4*) Number of LED sources 2 8 8 Measuring field M** ø 50 mm (2 in.) 100x100 mm (4x4 in.) 200x200 mm (8x8 in.) Min. object diameter 0.5 mm (.02 in.) 1 mm (.04 in.) 2 mm (.08 in.)
