• Strength : 320 T.
• Maximum length : 6100 mm.
• Distance between uprights : 5050 mm.
• Hydraulic control.
• Depth of the gooseneck : 350 mm.
• Numerical control : BARCO MNC 95 / C.
• Number of axes : 6.
• Approach speed : 80 mm / s.
• Working speed : 7 mm / s.
• Ascent rate : 70 mm / s.
• Distance between the table and the slide: 500 mm.
• Adjustment of the slide: 0 to 250 mm.
• Width of the table: 250 mm.
• Motor: 30 kw.
• Approximate weight: 28000 kg.
