Presentation

ELECTRICAL CHARACTERISTICS

• Power Supply: 220V.

• Ultrasonic power: 80W (160W p-p).

• Heating resistance: 100 W. ULTRASONIC CHARACTERISTICS

• Ultrasonic power: 80W (160W p-p).

• Working frequency: 40 Khz. Frequency scanning system (sweep system ± 2%).

• 1 high-performance IBL piezo-electric transducer on steel-titanium.

• Digital control board: - Main switch. - Ultrasonic time selection: from 0 to 60 min. - Temperature selection: from 0º to 80ºC. GENERAL CHARACTERISTICS AND COMPLEMENTS

• Tank made in stainless steel AISI 316.

• External panel made in print-free steel.

• 1 stainless steel basket.

• Stainless steel cover.

Technical features

Capacity: 1,5 liters Internal dimensions: 145x132x100 mm External dimensions: 175x160x260 mm Weight: 2,5 Kg Ultrasonic power: 80W (160W p-p). Working frequency: 40 Khz. Frequency scanning system (sweep system ± 2%). 1 high-performance IBL piezo-electric transducer on steel-titanium. Tank made in stainless steel AISI 316. External panel made in print-free steel. 1 stainless steel basket.

Download the complete technical features
