FINISHING AND ACCESSORIES
• AISI 304 stainless steel tank, 2 mm thick.
• Exterior steel panelling with a special anti-fingerprint finish. Easy to clean.
• K-Flex Duct Net thermal and acoustic insulation, 20 mm.
• Reinforced pneumatic platform for loading and immersing. Maximum load capacity: 250 Kg.
• ½” water inlet ball valve and a 1½” one for drainage.
• Silentblock legs, adjustable in height.
• Heat-insulated stainless steel end-of-day lid.
• Compressed air gun to dry parts.
Integrated system to separate lubricants and oils. Removes residue from the surface of the ultrasound tank, keeping the cleaning equipment in perfect condition.
• (Optional): filtering system (stainless steel filter with a polypropylene/polyester bag) for residue and mud
ELECTRIC CHARACTERISTICS
• Power Supply: 400V.
• Heating element: 7000W.
ULTRASONIC CHARACTERISTICS
• Ultrasonic Power: 3000W. (6000W. p-p).
• 1 ultrasound generator with an output power of 3000 W (6000 W p-p).
• Working frequency: 40 KHz with a frequency Sweep System (Sweep System ± 2%).
CONTROL PANEL
• 4.3” TFT LCF touch screen. Functional and intuitive; with access to select the time of the ultrasounds, temperature and peripherals or optional systems; and it is programmable on a weekly calendar.
• PLC with a temperature model fitted with 7 outputs and 7 inputs.
