After the very successful launch of the Trimos V-line height gauges, Trimos has developed a new instrument in its height gauge family, the V8.
The mechanical design and delivery scope of the V8 are identical to the V9 model. It shares the features that made other models so successful: extreme precision and repeatability, high resolution, and Swiss made finish. What is to underline about this new model is its specific handle for fine adjustment. Trimos developed this fine adjustment to answer to specific applications requiring a fine adjustment of carriage position.
The V8 guarantees, like its predecessors, an extremely easy use with great robustness, flexibility and extreme precision.
The large 2-line « Black Mask » display of the V8 offers an exceptional contrast in all lighting conditions. The display provides functions that are directly accessible and depicted with symbols easy to understand.
V8
4007001100
Measuring range
mm (in)
406 (16)
710 (28)
1109 (43)
Measuring range with extension
mm (in)
724 (28)
1028 (40)
1427 (56)
Max. permissible errors, BMPE
µm
1.2 + L(mm)/1000
Repeatability, RMPE (2s)
µm
0.5 (Ø:1)
Frontal squareness deviation, SMPE
µm
5
7
11
Maximal Resolution
mm (in)
0.001 (0.000005)
Measuring force
N
0.75 ÷ 1.5
Autonomy
h
12
Interfaces
USB / RS232
Air cushion
Yes
Weight
kg
22
25
34
