RA W N TIO ED G IN DL AN EH BL CA LS C TE RO EP BL EE ER BL CA BL CA CA TIC MA TO AU Catalogue n° 29 CO ILI N G MA CH IN E S Competence, reactivity and friendliness 75% of products shippable within D+1 Worldwide shipping Innovation and Quality contact@cable-equipements.fr Tel. : (+33) 01 45 90 14 14 www.cable-equipements.com 2 Document et photos non contractuels The main building of our factory, located in Noiseau (94), France For complete technical information on our products: 1) Scan this QR code 2) Enter the model name or its code in the search bar 3) Click on “Download the technical sheet” SUMMARY CABLE HANDLING - Cable drum unwinders - Coils and spools unwinders - Coilers with cranks - Cable cutters - Storage - Manual coiling - Measuring devices p. 4-5 p. 6-7 p. 7 p. 7 p. 8-9-10 p. 11 p. 12 COILING MACHINES - Safety first - After-sales service and maintenance - MOTO-COCCI coiling machine - ECO-COCCI machine (400 kg) - Cable machines up to 10 tons p. 13 p. 13 p. 14-15 p. 14-15 p. 16 CABLE DRAW - Pulleys - Electric winches - Cable pulling grip - Cable drums trailers - WALLY pulling rods - WALLY STICK pulling rods - SUNNY pulling rods p. 17 p. 17 p. 17 p. 17 p. 18 p. 19 p. 19 AUTOMATIC CABLE REELS - Grounding - 3G1,5² - 3G2,5² IP42 - 3G2,5² IP65 - 4G2,5² - 5G2,5² - DATA , ATEX, High power, Multi-strand - STEEL industrial models - Emergency vehicle power supply - Battery charging - Portable lights - Reels with portable lights - Signaling reels - Balancers - MAGIC REEL automatic extender - GREEN REEL electric car charging - Accessories - Hose reels p. 20 p. 21 p. 22 p. 23 p. 24 p. 25 p. 26 p. 27 p. 28 p. 28 p. 28 p. 28 p. 29 p. 29 p. 29 p. 30 p. 30 p. 31 CABLE PROTECTION - Pedestrian crossing - Vehicule crossing - Person with reduced mobility crossing - Cable sheath - Speed bumps - Gutters p. 32-33 p. 34-35 p. 35 p. 33 p. 34 p. 35 Some vocabulary clarifications A COIL A SPOOL A CABLE DRUM is a free roller without a central hub or flanges, generally delivered in a cardboard box, in a blister pack or simply tied with a string. has a central hub and flanges. It can be made of plastic, cardboard, plywood... is a large spool, most often made of wood and sometimes hooped, but also made of plywood, plastic, and metal. 3
