Fiber laser marking system FL - REA JET FL

Laser marking

Ask for a quote

Presentation

Fiber laser marking systems are part of the solid-state laser group. The laser beam is created in a diode-activated optical fiber. The REA JET FL is suitable for permanent the marking of metal and plastic surfaces. The marking with codes, texts, numbers or logos may even take place on oily, corroded or above 1000°C hot surfaces.

Applications
- engraving and annealing metals
- color inscription of untreated and with additives doped plastics
- day and night design
- coated substrates

Technical features

Laser Unit: FL 20, FL 30, FL 50 Laser power: 20W, 30W, 50W Pulse energy: 1 mJ Optimum pulse energy: 20 kHz / 30 kHz / 50 kHz Variable pulse frequency: 2 kHz – 200 kHz Pulse length / Wave length: 100 ns / 1064 nm Beam quality: M² – 2.0 (optimized for marking) Dimensions laser unit (L x W x H): 420 x 70 x 82 mm Weight laser unit: 1.5 to 2.5 kg Dimensions terminal (W x D x H): 302 x 230 x 66 mm

Download the complete technical features
