Ethernet data logger with 16 analog inputs MSX-ilog-AI-16

Ask for a quote

Presentation

The intelligent Ethernet data logger with 16 analog inputs MSX-ilog-AI-16 has 16 differential inputs, 16 bit, with a throughput rate of 1 KHz per channel. It was developped for the long-term data acquisition in the field and data visualisation and thus comes with an 4 GB build-in flash memory. The acquired data is processed onboard and transformed into physical values, such es mm, bar, C° etc. The parametering and visualisation of the measured values are carried out via an integrated web site. Thus no additional software installation is needed. The acquisition, visualisation and data storage take place automatically. Thanks to the degree of protection IP 65, numerous protective circuits and an operating temperature from -40°C to +85°C it is also suitable for use outside.

Technical features

Download the complete technical features
