- Composed of 3 springs.
- Absorbs vibrations and jolts.
- Use in both directions of rotation.
- No maintenance.
- Accepts temperature peaks of 100 ° C.
- Resistant to hydrocarbons.
- Maximum angular misalignment: from 3 to 6 ° depending on the length.
- Parallel misalignment: from 3 to 6% of the bore (d1) depending on the length.
- Fixing by key or pin.
The machining done by us is :
- H7 tolerance for bores.
- Standard keyway according to DIN 6885/1.
- Two pressure screws: one on key, the other at 120°.
Other work on request .
