BINDER GMBH

Dynamic climate chambers for rapid temperature changes with humidity control - Series MKF

Dynamic climate chambers for rapid temperature changes with humidity control - Series MKF - BINDER GMBH

Dynamic climate chambers for rapid temperature changes with humidity control - Series MKF - Test chamber

Dynamic climate chambers for rapid temperature changes with humidity control - Series MKF - produit présenté par BINDER GMBH

Dynamic climate chambers for rapid temperature changes with humidity control - Series MKF

Ask for a quote

Presentation

Temperature range: -40 °C to 180 °C
Humidity range: 10 % to 98 % RH
Integrated water-storage tank, 20 liters
4 zero-voltage relay contacts that can be activated via MCS controller
1 stainless steel rack
APT.line™ preheating chamber technology
Programmable condensation protection for test material
Heated viewing window with LED interior lighting
Humidity regulation with capacitative humidity sensor and vapor humidification
BINDER APT-COM™ 3 Basic Edition communication software
Troubleshooting system with visual and audible alarms
Controller with time-segment programming
Access port with silicone plug (Models 115, 240: 50 mm, left)
2 access ports with silicone plugs (Model 720: 80 mm, left and right)
Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
4 castors, two with brakes
Computer interface: Ethernet
230 V power socket on the right-side control panel
Display via color LCD monitor
Adjustable ramp function
Integrated chart recorder
Real-time clock
Door heating
Alarm notification in the event of insufficient water in fresh water tank
Complete safety connection kit for water supply and drainage, up to 1 m height
BINDER test confirmation
Inner chamber made of stainless steel
Pt 100 temperature sensor
Thermal insulation using PUR foam
CFC-free refrigerant R-404A
Cooling with compressor cooling unit
Fin evaporator
