Dual-in-line Switches

Specifications:
Contact rating: 50 V DC, 100 mA
Contact resistance: < 50 m?
Insulation resistance: > 1000 M? at 100 V DC
Capacity: < 5 pF between 2 poles
Dielectric strength: 500 V, 50 Hz for the duration of 1 minute
Operating temperature: – 20° to + 80° C
Mechanical life: minimum 25 000 operations per pole
Shock resistance: contact interruption < 10 ?sec with triple shock in all 6 directions
shock conditions: 20 G, 11 msec duration (sine half wave)
Vibration: contact interruption < 10 ?sec at vibration test in accordance with
MIL-STD-202 D, method 204, condition C
Contact/Terminals: PC terminals, phosphor bronze, 2 ?m gold-plated over 1 ?m nickel
Material: case: PBTP, slide: PA
Construction: case sealed
series 300: slide recessed, sealed with protective tape
Slide position: OFF
Mounting: on pc-board
Soldering conditions: auto-soldering – max.: 3 sec, 270º C
