Double-head cutting-off machine with 3 or 5 controlled axes - Precision T2/T2 E/T2 E-HS

Double-head cutting-off machine with 3 or 5 controlled axes - Precision T2/T2 E/T2 E-HS - EMMEGI FRANCE

Double-head cutting-off machine with 3 or 5 controlled axes - Precision T2/T2 E/T2 E-HS - Pipe cutting machine

Double-head cutting-off machine with 3 or 5 controlled axes - Precision T2/T2 E/T2 E-HS - produit présenté par EMMEGI FRANCE

Double-head cutting-off machine with 3 or 5 controlled axes - Precision T2/T2 E/T2 E-HS

Pipe cutting machine

Ask for a quote

Presentation

Double-head cutting-off machine with 3 or 5 controlled axes for aluminium, PVC and light alloys with automatic movement of the mobile head and electronic management of all 45° (internal) to 15° (external) angles, with a precision, within each degree, of 280 positions.

In the basic version blade advancement is driven by a couple of hydro-pneumatic cylinders. In version E this advancement is also managed by a couple of CN axes, to ensure optimal speed regulation and output travel of the blades. 550mm-blade Available with a useful cut of 5 m or 6 m in length.

The HS High Speed version envisions an X axis with higher speed and all necessary protections for the automatic work, even unattended, in order to obtain maximum production.
