Controls : Software : WINPAC

The menu of the WINPAC software package has been specially designed for creating an efficient program. The WINPAC program development system enables not only programdiagnosis in automatic operation, function up and download of all programs and settings of the PA-CONTROL but also remote diagnosis via modem.

B>Axis configuration:

he PA-CONTROL will be configured through the WINPAC program. With plug-in an optional module, the PA-CONTROL recognize the connected Hardware after switch on and takes on automatically the standard configuration.
In the basic configuration we vary between following parameter groups:

- system parameter.
- motor parameter.
- axis parameter.

The program editor:

The clear and distinct structure of the command blocks makes programming easy for newcomers:

- windowing technique.
- copying function.
- search/ replace function.
- Syntax checking.

Program diagnosis:

In the diagnosis window a program can be observed ONLINE. In separated diagnosis windows, the user can display intresting setups like input/output, flags, register, Profibus DP and RS232 which can be changed ONLINE. This diagnosis assists you in eliminating program errors efficiently and quickly.
