Automatic Pneumatic Grommeting Machine for Metallic Eyelets : 29-FEI

Eyelets for printing

Ask for a quote

Presentation

Punches and sets eyelets/grommets with washers in one operation.Powerful, fast, safe and quiet setting action.
With automatic eyelet/grommet and washer feed by means of Hopper and Raceway.

Can set eyelets/grommets from 8 to 16 mm internal hole. it can set 38 eyelets/washers per minute.All the moveable parts are protected to avoid injuries.

Particulary suitable for applications subject to stress forces as secure fixing is ensured by use of washer.Fully pneumatic machine so electricity is not needed.

Easy and fast change of raceways.Noise level 70db.

Technical features

Throat depth : 11,5 cm Eyelet size : 6 a 16 mm Stroke : 1 sg. Head sizes : 45x45x70 Sizes with bench : 80x65x158 cm Weight with bench : 88 Kg Working air pressure : 6 Kg Air consumption per cycle : 1,1 L Pounds of force : 10.000 Tons of force : 4.7
