‘Expert’ Weight Transmitter: Model DXP-40

The DXp-40 digital transmitter individually

digitizes each transducer in a multi-cell

weigh system for the purposes of greater

system resolution and accuracy, and

continuous diagnostics of system and

transducer performance. In addition to the

benefits of operational security, keypad

calibration of each transducer eliminates

the need for on-site deadweight calibration

on many systems. Optional Dynamic

Digital Filtering maximizes stability and

dynamic response by continuously

analyzing system noise characteristics and

automatically adjusting software filtering

parameters.

The optional 16 bit analog output provides

a high-resolution weight data interface for

non-digital process control equipment.

Available discrete l/O points (4 inputs and

4 outputs) offer local setpoint control or

diagnostic alarm status annunciation.

DXp-40 units provide designers with a wide

range of communication and network

options. Available ‘Easy Digital Interfaces’

include Allen-Bradley Remote I/O, Modbus

RTU, and conventional ASCII.

The DXp-40 is housed in a NEMA 4 or 4X

enclosure and carries FM/CSA Approvals

for Division 2 hazardous locations.
