“ EASY: full standalone application, user-friendly and out of the box, based on Microsoft and DWG/DXF standards FAST: easy navigation through the project, automated creation of PLCs, automatic 3D cable routing and wiring , automatic calculation of cable and wire lengths, automatic generation of the flatten harness from the 3D view. INTEGRATED: changes in real time to and from SolidWorks for a seamless collaboration with mechanical team, integration with PDM systems and SolidWorks Enterprise PDM SERVICES: tutorials to get you started, worldwide technical support based on a web ticket system, a content community, an interface available in multiple languages, a partnership with leading SolidWorks resellers worldwide. ”

Ask for a quote

Presentation

Elecworks is a full standalone electrical CAD solution which can be used as a SolidWorks add-ins for integrating 2D schematic electrical data into mechanical 3D views, optional Routing and Cabling module for automatic 3D wiring of a panel or a machine.

Certified GOLD SolidWorks application for the integration of 2D-3D electrical design

Elecworks is the only Certified GOLD SolidWorks application for electrical design. For SolidWorks users, the seamless integrations enables collaborative and simultaneous work on a same project with real-time updates to and from SolidWorks and Elecworks, through a unique database.

A large database of electrical components via TracePartsOnline

elecworks integrates all library needs to design a complete installation: electricity, automation, pneumatics, hydraulics, etc.. elecworks has a large database of 2D-3D smart components (TraceParts technology and partnership: over 100 million 3D components on the portal TracePartsOnLine).

A realistic visualization of the project

With its new features, elecworks boosts productivity and simplifies electrical design: maximum flexibility in the management of PLCs, automatic connection labels, automated 3D wiring with an accurate visualization of congestion, a collision detection to avoid overlapping wires and filling factor calculations. Elecworks is pushing the boundaries of electrical design by visualizing projects in a 3D view as realistic as possible.

Elecworks has unique features:

• single-line diagram for costing prior to scheme development

• panel design in 2D or 3D layout

• electrical harness design in 2D and 3D with automatic calculation of actual lengths of cables and wires and an automatic generation of the flatten routes

• highly flexible PLC management with automatic generation of PLC drawings independently of the manufacturer reference and dynamic integration of PLC drawing according to user's choices

• automatic 3D routing and wiring module for wires and cables

• smart electrical components which are able to position and connect automatically (based on TraceParts technology).
