HURON universal milling machine - Type: MU 6

Milling unit

Ask for a quote Receive Documentation Contact the supplier

• Longitudinal stroke - X: 1500 mm
• Cross travel - Y: 700 mm
• Vertical stroke of the table: 550 mm
• Surface of the table: 2000x460 mm
• Spindle cone: SA 50
• Number of grooves: 5
• Maximum distance between the spindle axis and the table: 540 mm
• A ram
• Number of spindle speeds: 27
• Spindle speed: 30 to 2066 rpm
• Number of longitudinal and transverse advances: 27
• Automatic longitudinal and transverse feeds: 1.6 to 820 mm / min
• Number of vertical advances: 27
• Vertical feeds: 0.8 to 410 mm / min
• Fast forward X and Y: 2800 mm / min
• Fast forward Z: 1400 mm / min
• Engine: 10 hp
• Engine advances: 3.5 hp
• Approximate weight: 4000 kg
•  Overall dimensions: 2335x2462x1740 mm

Accessories :

- 3-axis view.
- Speed variator.
